- Place of Origin: yishui
- Brand Name: sanzheng
- Model Number: Q1313-1B
Model and specifications | Q1313-1B |
Guideway width | 550mm |
Max.swing over bed | 630 mm |
Max.swing over carriage | 350mm |
Max.workpiece length | 1.5/3 mm |
Hole through spindle | 130mm |
Max.processing Pipe diameter | 126 mm |
Number of spindle speed changes | 18 steps |
Range of spindle speed changes | 12～640 r/min |
Range and number of whitworth thread | 28～2/40 |
Range and number of metric thread （mm） | 1～14/24 |
Power of main motor | 7.5/11kw |
Max.processing length of taper ruler | 500 mm |
Rapid traverse speed | 4000mm/min |
Processing workpiece precision | IT7 |
Workpiece surface roughness | Ra1.6 |
Machine net weight | 4200kg |
Max. load weight | 2000kg |
- Place of Origin: yishui
- Brand Name: sanzheng
- Model Number: Q1313-1B
Model and specifications | Q1313-1B |
Guideway width | 550mm |
Max.swing over bed | 630 mm |
Max.swing over carriage | 350mm |
Max.workpiece length | 1.5/3 mm |
Hole through spindle | 130mm |
Max.processing Pipe diameter | 126 mm |
Number of spindle speed changes | 18 steps |
Range of spindle speed changes | 12～640 r/min |
Range and number of whitworth thread | 28～2/40 |
Range and number of metric thread （mm） | 1～14/24 |
Power of main motor | 7.5/11kw |
Max.processing length of taper ruler | 500 mm |
Rapid traverse speed | 4000mm/min |
Processing workpiece precision | IT7 |
Workpiece surface roughness | Ra1.6 |
Machine net weight | 4200kg |
Max. load weight | 2000kg |
